High quality Australia type shutter door garage slat rolling machine - ZTRFM
Australian type roller shutter door is widely used in shops, shopping malls, schools, villas, factories, stations, banks and factories. It is the best alternative to aluminum roller shutter.
Features: the appearance of Australian roller door is novel and beautiful. Compared with other roller doors, Australian roller door has the characteristics of light, static and fast; The door panel is wavy and integrated, which is not easy to be stained with dust and oil. It can be cleaned with water, which is time-saving and convenient.
Cangzhou Zhongtuo can customize high-quality machines for you according to your requirements and provide you with several satisfied solutions
Packing list of Australia type shutter door making roll forming machinery:
| 3 Tons Decoiler | Manual |
| Roll forming system | Gear transmission |
| PLC control system | Delta brand |
| Hydrauilc system |
YUKEN STANDARD
|
| Production collect table |
Manual/3m length
|
Techincal parameter:
| Material | PPGI/GI |
| Thickness | 0.4-0.6 mm |
| Cutting length | Adjustable |
| Decoiler | 5 Tons manual type |
| Roller shaft material | 45# steel |
| Roller station | 14 roller stations |
| Shaft diameter | 80 mm |
| Machine frame | Middle plate structure |
| Machine speed | 20 m/min |
| Main motor power | 7.5 KW |
| Control system | PLC control system |
| Function | Control the quantity, length, speed and can set up orders on it. |
| Product collect table | 3 m length |
